University of Michigan Lane Hall Renovations

Fall 2019

Software used: Auto CAD, SketchUp, PhotoShop, PowerPoint

The new Lane Hall takes advantage of the nature environment, and to integrate the indoor and outdoor space as much as possible. The users’ safety and emotional/physical health are the main priority of the new Lane Hall. By including more calming and relaxing color and Japanese style features the new Lane Hall provides a soothing space for the users.
